FGM
Formosa Automation Systems Inc.
| Motor Power: | 2.24-7.46 kW |
|---|---|
| Rotor Diameter: | -- |
| Region: |
Taiwan
|
Product Characteristics
| Model No. | FGM 2520 | FGM 2525 | FGM 2530 | FGM 2535 | ||
|---|---|---|---|---|---|---|
| Price per Unit | ||||||
| General Data | ||||||
| Product Warranty | ||||||
| Throughput | 40 - 80 Kg / Hr | 50 - 100 Kg / Hr | 60 - 120 Kg / Hr | 70 - 150 Kg / Hr | ||
| Screen Diameter | 8 mm | 8 mm | 8 mm | 8 mm | ||
| Motor | ||||||
| Motor Power | 2.24 kW | 3.73 kW | 5.59 kW | 7.46 kW | ||
| Rotor | ||||||
| Rotor Diameter | ||||||
| Rotor Length | ||||||
| Rotor Speed | 480 rpm | 480 rpm | 480 rpm | 480 rpm | ||
| Knives | ||||||
| Rotating Knives Number | 2 Pcs | 2 Pcs | 3 Pcs | 3 Pcs | ||
| Rotating Knives Size | ||||||
| Stationary Knives Number | 2 Pcs | 2 Pcs | 2 Pcs | 2 Pcs | ||
| Dimensions & Weight | ||||||
| Overall Dimensions (LxWxH) | 950x500x1490 mm | 950x550x1490 mm | 950x600x1490 mm | 950x650x1490 mm | ||
| Cutting Chamber Size (LxW) | ||||||
| Hopper Opening Size (HxW) | 250x200 mm | 250x250 mm | 250x300 mm | 250x350 mm | ||
| Weight | 360 Kg | 400 Kg | 500 Kg | 600 Kg | ||
