HJCH
Hanjin Ind
| Max Number of Strands: | 10-100 |
|---|---|
| Motor Power: | 5.5-37 kW |
| Region: |
Korea
|
Product Characteristics
| Model No. | HJCH-1 | HJCH-2 | HJCH-3 | HJCH-6 | HJCH-9 | HJCH-10 |
|---|---|---|---|---|---|---|
| Price per Unit | ||||||
| General Data | ||||||
| Product Warranty | ||||||
| Throughput | 1250 Kg / Hr | 2500 Kg / Hr | 3400 Kg / Hr | 6500 Kg / Hr | 10000 Kg / Hr | 11000 Kg / Hr |
| Category | Strand | |||||
| Type | Underwater | |||||
| Cut | Wet Cut | |||||
| Motor | ||||||
| Motor Power | 5.5 kW | 7.5 kW | 15 kW | 22 kW | 37 kW | 37 kW |
| Pelletizing Parameters | ||||||
| Max Number of Strands | 10 Pcs | 20 Pcs | 30 Pcs | 60 Pcs | 90 Pcs | 100 Pcs |
| Draw-in Speed Range | 60 - 250 m/min | 60 - 250 m/min | 60 - 250 m/min | 60 - 250 m/min | 60 - 250 m/min | 60 - 250 m/min |
| Standard Pellet Length | ||||||
| Cutting Rotor Diameter | ||||||
| Dimensions & Weight | ||||||
| Overall Dimensions (LxWxH) | ||||||
| Draw-in and Cutting Width | 160 mm | 250 mm | 350 mm | 680 mm | 952 mm | 1096 mm |
| Weight | ||||||
